An Aluminum/Delrin high-mass body DIM phono cartridge featuring high internal impedance and high gain to achieve great sound performances matched with any MM phono preamplifier.
Bobolino’s aluminum alloy light and rigid cantilever handles a high precision Elliptical diamond for perfect structural rigidity.
The cantilever suspension, made in a double elastic polymer, is inserted into a brass pipe to eliminate vibrations and to enhance tracking cability for the best reproduction possible.
The light and dampened body of the cartridge, less then 9g of mass, enables a superb vibration control and easy tone-arm matching.
Due to its 600ohm high internal impedance and 3.0mV output level, Bobolino Series can be easily coupled with any active phono preamp MM at a suggested load of 47kΩ.
The Bobolino series is available in two models: Bobolino Gold with an output level of 3.0mV and Boblino Red with the same output level.
TYPE
Dual Inductive Magnet Design Phono Cartridge
OUTPUT LEVEL
3.0mV
FREQUENCY RESPONSE
Gold: 20-20000Hz
Red: 20-30000Hz
IMPEDANCE
600Ω
SUGGESTED LOAD
Gold: 470Ω
Red: 47Ω
COMPLIANCE
15×10-6cm/dyne
CHANNEL SEPARATION
Gold: > 23dB
Red: > 25dB
SUGGESTED TRACKING WEIGHT
1.5g to 1.8g
CANTILEVER
Aluminium
DIAMOND
Elliptical
COIL WIRE
Copper
MOUNTING HOLE DIAMOND DISTANCE
9mm
WEIGHT
Gold: 7,5g
Red: 9g
BODY
Gold: Delrin body, Black with White Logo
Red: Anodised Aluminium & Delrin, Black with Red Logo
