Bellagio Conquest

Made for the most demanding vinyl lovers, Bellagio Conquest is a real statement High-End turntable.

HIGH-END TURNTABLE
The Bellagio Conquest is available as part of our exclusive Limited Edition turntable series. This massive floor-standing structure weighs 100kg. It features an amazing 270mm platter spindle and an exclusive adjustable high-power motor control.
With its 125cm of height, this formidable turntable is capable of exceptional platter rotation stability and fluidity, distributing all kinetic forces along the spindle’s axis. It produces absolutely fantastic and unbeatable audio performances.
Bellagio Conquest is a real statement vinyl source made only for the most passionate and pure turntable lovers. It shines bright like a diamond in the highest premium class of High-End audio.

THIRTEEN DIFFERENT CURVED PLINTHS
Conquest is the only turntable to feature thirteen different curved plinths achieving maximum stiffness and indeformability while allowing the best resonance feedback control: the plinths are interfaced with titanium spacers of different thickness joined together with custom machined solid blocks of aluminium and extra-large feet.

The 270 mm spindle is the longest spindle ever made for a turntable! Created from the hardest carbon steel C40 alloy hardened with a boiling oil process, rectified and polished to guarantee the best working fluidity. Polished bronze is used for the bearing, engineered to get a 1/100 millimeter matching tolerance with the spindle: the amazing length of the system is capable of the smoothest platter rotation available and forces distribution control along the spindle’s axis to deliver fantastic audio performances.

POWER CONTROL AND HOURGLASS MOTOR PULLEY
To power our best turntable we chose our best technology, a PWM generator – Pulse Width Modulation: the PWM power drive generates AC-DC-AC enabling the best coupling of the two AC semi-wave annulling motor resistance and vibrations and still maintaining the highest torque. The new anti-resonating dampened hourglass shaped motor pulley stops transmission vibrations; it’s precisely machined and polished to achieve perfectly smooth surfaces and guarantee low rotational noise and great durability.

Technical specifications

WOW & FLUTTER

0,05%

RUMBLE

-85dB

SPEED

33-1/3 and 45 rpm +/-0,1%

SPEED CHANGING

electronic fully remotable with fine pitch control

TRANSMISSION

70 shores elasticity rectified black EPDM Deluxe belt

MOTOR

12V High Torque synchronous externally powered

MOTOR CONTROL

Electronic speed control

PLATTER

Sustarin® 110mm height

PLATTER SPINDLE

270mm hardest carbon steel C40 alloy clamping platter and bronze polished bearing housing

PLATTER BEARING

Ceramic 4,7mm ball bearing

PLATTER ROCKER ARM

550mm rocker arm with elliptical counterweight

POWER SUPPLY

100V-240V, 50 or 60Hz depending on market destination, not convertible

POWER CONSUMPTION

20W

DIMENSIONS

530mm W | 1250mm H | 500mm D

WEIGHT

Kg. 100

SUSPENDED PLINTH

Triple Black Polished Acrylic

MAIN PLINTH

Five double Black Polished Acrylic and Titanium

METAL PARTS

Silver, Black and Chrome

PLATTER

Black
