PSU-10 EVO

The inductive power supply dedicated to the DS-10 and DS-10 PLUS

THE PERFECT ADD ON

The PSU-10 EVO has been engineered with the finest audio grade components to enhance the performance of DS-10 and DS-10 PLUS even further. The PSU-10 EVO features a 4-transformer power supply stage enhanced with ultra-low-noise voltage regulators. The power supply stage takes advantage of a 4-transformer layout with 3 transformers entirely dedicated to the power supply and 1 for the inductive filter.
The Dual Choke Hybrid design features an inductive filter on the analogue stage and is powered by a double inductor, driving both the negative and positive high-current stages. This proprietary technology perfectly filters the current to eliminate interference and electrical noise from the AC power system achieving ideal insulation, an ideal working environment for the electronics to perform at their best.

ULTRA-CLEAN POWER

The ultra-clean power generated by the PSU-10 EVO allows DS-10 and DS-10 PLUS to deliver greater dynamics, better resolution, and even finer details resulting in improved realism, musicality as well as control.

Please note: the PSU-10 EVO is not compatible with the PH-10 Phono Stage

Technical specifications

TECHNICAL FEATURES

Four rail audio grade power supply

Two ultra-low-noise voltage regulators

MAXIMUM VARIATION OF OUTPUT VOLTAGE

0,05 %

LINE NOISE REJECTION

>80dB

COMMON MODE NOISE REJECTION

>80dB

FULL POWER RESPONSE TIME

<2,5µsec

POWER SUPPLY

100-120V / 220-240V with auto sense, 50/60Hz

POWER CONSUMPTION

70W

DYNAMIC POWER

>100W

STAND BY POWER

<1W

FUSE

0,5A T

DIMENSIONS

200mm W | 80mm H | 260mm D

WEIGHT

Kg. 4 – net

Kg. 5 – boxed

BLACK


Black anodised aluminium with a traditional brushed finish

SILVER


Silver anodised aluminium with a traditional brushed finish

GOLD


Gold anodised aluminium with a traditional brushed finish

PSU-10

1100,00€

PSU-10 evo rear
