Pianosa

The attention to the smallest details awakens new musical sensations

OUTSTANDING MATERIALS

The Pianosa, just like the Mediterraneo and the Giglio, offers a unique combination of high-quality materials and refined technical solutions to achieve the purest audio execution.

The Pianosa follows the sonic philosophy experimented with the full range of GN turntables, taking advantage of the experience and knowledge we developed working on innovative shapes and quality materials.

The “catenary” curved plinth, made of Italian walnut hardwood or black lacquered MDF, is handcrafted by the best Italian wood-making artisans who carefully treat every single piece of selected wood, shaping the core of the turntable.

The wooden plinth is coupled with a 20mm thick MDF plinth and reinforced with a 3mm stainless steel plate to provide incredible rigidity.

The result is an audio performance that exceeds any expectations.

OUTSTANDING SOUND

The electronics that control the power driving the 12V synchronous motor and the specific materials chosen for the Pianosa come directly from the flagship models. It results in a zero vibrations device and an improved torque delivering the greatest dynamic and the finest detail.

The Pianosa features our high-precision platter bearing/spindle design with the lowest coupling tolerance available. The rectified spindle is made of hardened steel and it precisely matches the chromed ball bearing, reaching the perfect low noise rotational consistency.

Technical specifications

WOW & FLUTTER

0,1%

RUMBLE

-77dB

SPEED

331⁄3rpm and 45rpm ±0,1%

SPEED CHANGING

Electronic with fine pitch control

TRANSMISSION

70 shores rectified NBR belt

MOTOR

high torque 12V synchronous

PLATTER

23mm Dampened Poly-Vinyl

PLATTER SPINDLE

Split-Spindle™ clamping design

PLATTER BEARING

Chromed Steel 5mm ball bearing

TONEARM

Gold Note B-5.1

DUST COVER

Transparent with hinges

POWER CONSUMPTION

max 27W

POWER SUPPLY

18V output

100-240V / 50-60Hz

DIMENSIONS

425W | 200H | 360D mm

550W | 480H | 480D mm – boxed

WEIGHT

Kg. 13.5 – net

Kg. 18 – boxed

ITALIAN WALNUT
With black lacquered MDF upper plinth,
black anodized aluminium metal parts
and black platter

BLACK LACQUERED MDF
With black lacquered MDF upper plinth,
black anodized aluminium metal parts
and black platter

EXTERNAL POWER SUPPLY

PST-10 external inductive power supply for turntables

TONEARM

B-7 Ceramic

PIANOSA ITALIAN WALNUT

2990,00€

PIANOSA BLACK LACQUER

2990,00€
