Discontinued Archives

POWER OUTPUT 60w + 60w @ 20-20000Hz FREQUENCY RESPONSE 20Hz – 20KHz @ +/- 3dB SIGNAL TO NOISE RATIO -105dB ANALOGUE INPUTS 5x RCA and 1x XLR AUDIO OUTPUT Speaker connectors, 1 stereo RCA (optional variable)

POWER OUTPUT 30w+30w @20-20.000Hz FREQUENCY RESPONSE – 20KHz @ +/- 3dB SIGNAL TO NOISE RATIO -90dB ANALOGUE INPUTS Line + 1X phono (optional) AUDIO OUTPUT 1x fixed output

POWER OUTPUT 100W @20-20.000Hz FREQUENCY RESPONSE 20Hz – 20KHz @ +/- 3dB SIGNAL TO NOISE RATIO -90dB ANALOGUE INPUTS RCA 6 XLR INPUT IMPEDANCE 47Kohm INPUT SENSITIVITY 550mV

Beauty and technical perfection. Together, for the pleasure of listening.

POWER OUTPUT 200W @20-20.000Hz FREQUENCY RESPONSE 20Hz – 20KHz @ +/- 3dB SIGNAL TO NOISE RATIO -90dB ANALOGUE INPUTS 1x RCA, 1x XLR balanced INPUT IMPEDANCE 47Kohm INPUT SENSITIVITY 550mV

POWER OUTPUT 100+100W at 20-20000Hz FREQUENCY RESPONSE 5Hz-30kHz at +/-1dB DAMPING FACTOR >150 ANALOGUE INPUTS 4x RCA, 2x XLR stereo PREAMPLIFIER OUT 2x stereo RCA SPEAKER TERMINALS Gold Note BP-01 Rhodium Plated Binding Post

POWER OUTPUT 50+50W at 20-20,000Hz FREQUENCY RESPONSE 10Hz-25kHz at +/-1dB DAMPING FACTOR >100 ANALOGUE INPUTS 4x RCA, 2x XLR stereo PREAMPLIFIER OUT 2x stereo RCA SPEAKER TERMINALS Gold Note BP-01 Rhodium Plated Binding Posts

POWER OUTPUT 75W@ 8Ω and 150W @ 4Ω per channel, 600W @ 4Ω per channel in mono (BTL) FREQUENCY RESPONSE 10Hz-30kHz at +/-1dB TOTAL HARMONIC DISTORTION (THD) 0,05% DAMPING FACTOR high (250) or low (25) AUDIO INPUTS 1x RCA unbalanced, 1x XLR balanced POWER SUPPLY 100-240V / 50-60Hz

FREQUENCY RESPONSE 35 – 30000 Hz CROSSOVER 200Hz and 2200Hz @ 12dB/Oct. SUGGESTED POWER AMPLIFIER min. 30W TWEETER Ribbon AMT MIDRANGE 1x 6“ custom GN made by SEAS woven polypropylene WOOFER 2x 6,5“ custom GN made by SEAS woven polypropylene

FREQUENCY RESPONSE 40-20000Hz ±3dB MAX POWER HANDLING 150W RMS CROSSOVER 60Hz and 2000Hz @ 12dB/Oct. TWEETER 1” AUDAX silk dome driver MID-WOOFER 2 x 5’’ SEAS treated paper cones SUB-WOOFER 6’’ SEAS woven polypropylene cone

Beauty and technical perfection. Together, for the pleasure of listening.

FREQUENCY RESPONSE 45-20000Hz ±3dB CROSSOVER 2300Hz at 12dB/Oct. MAX POWER HANDLING 100W RMS SUGGESTED POWER AMPLIFIER min. 10Watt TWEETER 1” AUDAX silk dome driver MID-WOOFER 6’’ SEAS woven polypropylene

TECHNICAL FEATURES 24/192 asynchronous 2.0 USB to S/Pdif Converter FREQUENCY RESPONSE 20Hz-20kHz +/-0.3dB TOTAL HARMONIC DISTORTION 0.001% THD max SIGNAL TO NOISE RATIO -115dB INPUT 24/192kHz asynchronous USB port OUTPUT Digital S/Pdif (RCA Coaxial) 75Ω

POWER OUTPUT 200W@8Ω per channel (520W@8Ω in mono BTL) FREQUENCY RESPONSE 1Hz – 100KHz @ ± 1dB THD (TOTAL HARMONIC DISTORTION) <0.01% @ 20Hz-20kHz DAMPING FACTOR High (250) or low (25) AUDIO INPUTS RCA unbalanced and XLR balanced POWER SUPPLY 100-120V or 220-240V, 50/60Hz

FREQUENCY RESPONSE 2Hz – 200kHz @ ± 3dB THD (TOTAL HARMONIC DISTORTION) <0.001% @ 1kHz GAIN +20dB CHANNEL SEPARATION >118dB CHANNEL LEFT/RIGHT selectable swap MONO/STEREO Yes

THD (TOTAL HARMONIC DISTORTION) 0,001% @ 20Hz-20KHz ANALOGUE INPUTS 1x pair RCA Line input and 1x pair XLR balanced Line input INPUT IMPEDANCE proprietary design variable , 100% headphone matching stability AUDIO OUTPUTS 2 RCA and XLR preamp out, 2 RCA and XLR Line out

THD (TOTAL HARMONIC DISTORTION) <0.002% THD @ 20Hz-20KHz GAIN 70dB MC, 48dB MM INPUT IMPEDANCE 470Ω MC or 47kΩ MM AUDIO OUTPUTS stereo RCA and XLR balanced

THD (TOTAL HARMONIC DISTORTION) <0.05% THD @ 20Hz – 20KHz GAIN 65dB MC or 45dB MM INPUT IMPEDANCE 470Ω MC or 47kΩ MM AUDIO OUTPUTS 1x stereo RCA

POWER SUPPLY 100/115/230V, 50/60Hz, depending on market destination POWER CONSUMPTION 100W max POWER CONNECTIVITY professional waterproof CPC Tyco 9-pin plug SPEAKER TERMINALS Gold Note BP-01 Rhodium Plated Binding Posts

DAC D/A Converter native PCM up to 24bit/192kHz & DSD 64/128/256 native and via DoP NETWORK PLAYER AND STREAMER PCM and DSD64 FREQUENCY RESPONSE 5Hz-200kHz +/-0.3dB THD – TOTAL HARMONIC DISTORTION 0.001% max INPUTS 5 digital inputs and 1 analogue inputs OUTPUTS 2 analogue outputs and 1 digital output DIGITAL FILTER Gold Note Zero-Clock™ circuit enabling three different Master Clock DIGITAL VOLUME CONTROL enabled/disabled by remote

FREQUENCY RESPONSE 20Hz – 20KHz @ +/- 0,3dB THD (TOTAL HARMONIC DISTORTION) 0,001% max. solid state DYNAMIC RESPONSE 125dB CONTROL DIGITAL SYSTEM Zero-Clock™ ANALOG OUTPUT Stereo RCA and XLR balanced DIGITAL OUTPUT 75Ohm RCA connector

FREQUENCY RESPONSE 20Hz – 20KHz @ +/- 0,3dB THD (TOTAL HARMONIC DISTORTION) 0,05% max. DYNAMIC RESPONSE 127dB CONTROL DIGITAL SYSTEM Zero-Clock™ ANALOGUE OUTPUTS stereo RCA and balanced XLR DIGITAL OUTPUTS 75Ohm RCA connector

CD FORMATS Red Book DISC COMPATIBILITY CD, CD-R, CD-RW, MP3 MECHANIC Aluminium JPL-2800 Stream-Unlimited DIGITAL FILTER proprietary Zero-Clock™ circuit enabling three different Master Clock ANALOGUE OUTPUTS stereo RCA and balanced XLR COAXIAL DIGITAL INPUTS 2x RCA S/PDIF asynchronous 24/192

FREQUENCY RESPONSE 20Hz – 20KHz @ +/- 0,3dB THD (TOTAL HARMONIC DISTORTION) 0,05% max. DYNAMIC RESPONSE 127dB CONTROL DIGITAL SYSTEM Zero-Clock™ ANALOG OUTPUT Stereo RCA and XLR balanced DIGITAL OUTPUT 75Ohm RCA connector

CD FORMATS Red Book DISC COMPATIBILITY CD, CD-R, CD-RW, MP3 MECHANISM Aluminium JPL-2800 Stream-Unlimited DIGITAL FILTER proprietary Zero-Clock™ circuit AUDIO OUTPUTS Stereo unbalanced RCA and balanced XLR, S/PDIF Coax 75Ω DIGITAL INPUTS RCA S/PDIF coaxial,TOS asynchronous 24bit/192kHz (optional USB input)

TECHNICAL FEATURES 24/192 asynchronous 2.0 USB DAC USB INPUT 24/192 asynchronous USB port ANALOGUE INPUT stereo RCA and XLR balanced DIGITAL INPUTS 2x coaxial RCA, 1x optical TOS LINK FREQUENCY RESPONSE 20Hz-20kHz +/-0.3dB ANALOGUE OUTPUT stereo RCA and XLR balanced

High-End Streaming DAC: the new frontiers of digital music.

HIGH RESOLUTION STREAMING Roon Ready, Airplay, MQA, Qobuz, Deezer, Spotify Connect, Tidal, vTuner DAC AKM AK4493 PCM (32bit/768kHz, DSD512) ANALOGUE INPUT 3.5mm mini jack DIGITAL INPUTS 6 Inputs including TOS, Coax and USB FREQUENCY RESPONSE 20Hz-20kHz ± 0.1dB APP GN Control App for iOS and Android

FREQUENCY RESPONSE 20-20000Hz CHANNEL SEPARATION > 20dB IMPEDANCE 400Ω SUGGESTED LOAD 47Ω SUGGESTED TRACKING WEIGHT 1.5g to 2.0g DIAMOND Elliptical CANTILEVER Aluminium BODY Plastic and aluminium body, black and silver with white name

FREQUENCY RESPONSE Gold: 10-40000Hz - Red: 10-40000Hz CHANNEL SEPARATION Gold: >28dB - Red: >28dB IMPEDANCE Gold: 30Ω - Red: 40Ω SUGGESTED LOAD Gold: 470Ω - Red: 470Ω TRACKING WEIGHT 1.8g to 2.1g DIAMOND Gold: Line Contact - Red: Micro Elliptical CANTILEVER Gold: Boron - Red: Aluminium BODY Gold: Duralumin 7000 alloy - Red: Duralumin 7000 alloy

FREQUENCY RESPONSE Gold: 20-20000Hz, Red: 20-30000Hz CHANNEL SEPARATION Gold: > 23dB, Red: > 25dB IMPEDANCE 600Ω SUGGESTED LOAD Gold: 470Ω, Red: 47Ω SUGGESTED TRACKING WEIGHT 1.5g to 1.8g DIAMOND Elliptical CANTILEVER Aluminium BODY Gold: Delrin, Red: Anodised Aluminium & Delrin

WOW & FLUTTER 0,03% (0,04% Package) RUMBLE -80dB (-77dB Package) SPEED 33⅓rpm and 45rpm ±0,1% MOTOR 24 poles on double rail synchronous AC powered PLATTER Sustarin PLATTER BEARING Finely polished bronze made

WOW & FLUTTER 0,04% RUMBLE -76dB SPEED 33-1/3 and 45 rpm +/-0,1% MOTOR 24 poles on double rail synchronous AC powered PLATTER acrylic PLATTER BEARING graphite bearings

WOW & FLUTTER 0,3% RUMBLE -72db SPEED 33⅓rpm and 45rpm ±0,1% MOTOR high torque 12V synchronous PLATTER 20mm in MDF and POM PLATTER BEARING Split-Spindle™ clamping design
